Technical data
01| Nominal size | DN15 – DN200 |
|---|---|
| Pressure rating | PN16 |
| Service temperature | PTFE −196 °C … +260 °CFilled PTFE −196 °C … +260 °C Depends on the seal option; may be narrower depending on body and trim material. Exact value in the quotation. |
| Standard | DIN · JIS · ANSI |
| Connection type | Full bore · ISO mounting pad · Flanged |
| Design | DIN 3357 EN 12516-1EN 12516Industrial valves — shell design strength |
| Face-to-face dimension | TS EN 558 (Series 14-15)EN 558Face-to-face and centre-to-face dimensions of valves |
| Mounting pad | ISO 5211ISO 5211Actuator attachment (mounting pad) |
| Test | TS EN 12266-1EN 12266-1Industrial valves — testing of valves · pressure tests |
The standards listed apply to stocked products. Contact us for other standards.
Material
02| Material |
|---|
Accessories
03
Actuator
Actuators open and close industrial valves automatically. By removing the need for manual operation, they make processes safer and more efficient.
Limit switch box
Limit switch boxes are used in industrial automation to monitor the position of a valve or another moving mechanical part. They are usually combined with pneumatic and electric actuators, and can also be mounted directly on a manually operated valve.
Manual gear operator
Manual gear operators make it possible to operate large, high-torque valves by hand. The operator turns a handwheel or lever, and the gear mechanism opens or closes the valve.
Mounting bracket
Mounting brackets are mechanical supports for securely fitting actuators, gear operators and other accessories to a valve. They connect the valve body to the actuator and keep the assembly stable in operation.
Downloads
04Open datasheet
IN PREPARATION
Open sample
